Aluminum alloy profile high temperature tensile testing machine Longitudinal shear testing machine, universal testing machine selection

  The CMT-50 aluminum alloy profile high-temperature tensile testing machine developed and manufactured by Liangong can complete various mechanical performance tests such as high-temperature tensile test, longitudinal shear test, and torsion test of aluminum alloy doors and windows and other profiles, so it is also called microcomputer Control electronic universal testing machine.

  The Liangong CMT-50 profile high temperature tensile testing machine adopts a software management system independently developed and has a software copyright certificate. The system has a powerful test management function, and the test unit can be set arbitrarily according to the needs. The user can edit the corresponding test program according to different standards when using it. As long as the corresponding test program is selected, the test can be completed according to the standard requirements, and the test report meeting the standard requirements can be output. Real-time display of the test process and equipment status, such as: equipment operating status, program control operating steps, whether the extensometer is switched, etc. At the same time, it also has a powerful curve analysis function, which can choose load-deformation, load-time and other curves, and display one or more of them in real time. The curves of the same group of samples can be superimposed and compared with different colors, traverse the curve, any section of the test curve can be partially enlarged and analyzed, and support to display and mark each characteristic point on the test curve, and can also be automatically or manually on the curve Take the points for comparative analysis, and the curve with the characteristic points can also be printed out in the test report. The most important point is the automatic storage of test data to avoid loss of test data caused by accidents.


The main technical parameters:
1. Effective test width: 400mm
2. Effective tensile stroke: 700mm (can be customized according to user needs)
3. Effective compression stroke: 700mm
4. The overall dimensions of the host (length * width * height): (760 * 460 * 1900) mm
5. Temperature range: -40℃~+150℃;
6. Temperature accuracy: 0.3%;
7. The temperature fluctuation: ±0.5ºC;
8. Temperature uniformity: ±2ºC;
9. Cooling speed: 0.7~1℃/min;
10. Hollow electric heating glass observation window;
11. Temperature control: PID automatic temperature control.
